System Carrier Frequency UHF823-832MHz
System Bandwidth 9MHz
System Channel Bandwidth 100kHz
Preset Group/Channel 10 groups, 9 frequencies in each group
Dynamic Range >98dB
Total Harmonic Distortion <0.1%
Frequency Response 30Hz-20kHz / ±2dB
Audio Output Level Balanced 400mV; Unbalanced 400mV
System Packing Dimensions (WxHxD) 436 x 104 x 324 mm
System Packing Gross Weight 2.5 kg
Power Supply DC 12V / 1000mA
Receiver Consume Power 5W
Receiver Signal/Noise Ratio >98dB
Receiving Sensitivity -95dBm
Transmission Delay <3ms
Receiver Dimensions (WxHxD) 210 x 45 x 118 mm (antennas not incl.)
Receiver Antennas 255 mm (not bent)
Receiver Net Weight 0.4 kg
Transmitter Power 10mW (Max)
Modulation Type DQPSK
Battery Voltage Handheld Transmitter 1x 3.7V - 1200mAh Lithium Rechargeable Battery (type 18500)
Transmitter Continuous Using 5 hours (HI Trans. power); 7 hours (LO Trans. power)
Battery Charge Time About 3,5 hours
Hand-held Mic. Dimensions (W/DxH) Ø35 (min) - Ø46 (max) x 240 mm
Hand-held Mic. Net Weight 0.26 kg (batteries included)
